## Venn Chart

A Venn diagram (also called primary diagram, set diagram or logic diagram) is a diagram that shows all possible logical relationships between a finite collection of different sets. Each set is represented by a circle. The circle size represents the importance of the group. The groups are usually overlapping: the size of the overlap represents the intersection between both groups.

Example Color Themes

Example Fonts

Show Code

Tools

```<head>
<!-- Include the CanvasXpress library in your HTML file -->
<script src="https://www.canvasxpress.org/dist/canvasXpress.min.js"></script>

<body>

<!-- Create a canvas element for the chart with the desired dimensions -->
<div>
<canvas id="canvasId" width="600" height="600"></canvas>
</div>

<!-- Create a script to initialize the chart -->
<script>

// Create the data for the graph
var data = {
"venn" : {
"data" : {
"A" : 340,
"AB" : 639,
"ABC" : 552,
"ABCD" : 148,
"ABD" : 578,
"AC" : 456,
"ACD" : 298,
"B" : 562,
"BC" : 915,
"BCD" : 613,
"BD" : 354,
"C" : 620,
"CD" : 143,
"D" : 592
},
"legend" : {
"A" : "List 1",
"B" : "List 2",
"C" : "List 3",
"D" : "List 4"
}
}
}

// Create the configuration for the graph
var config = {
"graphType":"Venn",
"showTransition":false,
"vennGroups":"4"
}

// Call the CanvasXpress function to create the graph
var cX = new CanvasXpress("canvasId", data, config);

</script>

</body>
```
```library(canvasXpress)
canvasXpress(
vennData=data.frame(A=340, AB=639, ABC=552, ABCD=148, ABD=578, AC=456, ACD=298, AD=257, B=562, BC=915, BCD=613, BD=354, C=620, CD=143, D=592),
vennLegend=list(A="List 1", B="List 2", C="List 3", D="List 4"),
graphType="Venn",
showTransition=FALSE,
vennGroups=4
)```
